Organic EL undershelf lighting
TE270D
TE270D
Regular price
¥92,400
Regular price
Sale price
¥92,400
Unit price
per
Tax included.
Shipping calculated at checkout.
In stock
Couldn't load pickup availability
■Product features
・Next-generation inspection lighting This is an inspection lighting that can be placed freely according to the usage environment.
-The TE270 series allows for flexible placement of the positional relationship between the light and the workpiece.
■Product name
Organic EL undershelf lighting
■Model name
TE270D
■Product specifications
| lighting | |
|---|---|
| light source | organic EL lighting panel |
| Rated input voltage | 100-240V, 50/60Hz, A plug *By changing the cord with AC plug, it can be used up to 125-240V. |
| Rated power consumption | 13W |
| Illuminance adjustment function | Yes (100%~10%) |
| Illuminance directly below the center (Max) | 1120LX/150mm 360X/300mm 150LX/500mm (Actual sampling value, according to our measurement method) |
| Illuminance directly below the center (Min) | 80LX/150mm 25LX/300mm 10LX/500mm (Actual measured value, according to our measurement method) |
| color temperature | 4000K (white) |
| Average color rendering index (Ra) | 90 |
| Light emitting surface size (mm) | L273×W30 |
| Total luminous flux (lm) | 200 (per panel) |
| AC adapter model and rating | UNIFIVE336-2415(24V/1.5) Weight: 270g |
| Main body | |
| Weight (Kg) | 1.0 (including body weight controller) |
| Dustproof/waterproof protection grade | IP20 (for indoor use only) |
