fluorescent lighting magnifier
OLIGHT3-F
OLIGHT3-F
In stock
Couldn't load pickup availability
■Product features
- A compact fluorescent tube is used as the light source, making it possible to ensure sufficient illuminance despite its small size.The lighting system uses an inverter circuit board to suppress the "flickering" characteristic of fluorescent tubes.
・The square lens has distortions cut out on the outer periphery and can be used for long hours of work.By using the optional "AR coat" lens with an anti-reflection coating on the lens, the lens can be used for long periods of time. It suppresses reflection and increases the amount of light transmitted, reducing the burden and fatigue during work.
■Product name
fluorescent tube lighting magnifier
■Model name
OLIGHT3-F type (free arm type)
■Product specifications
| lens | |
|---|---|
| magnification | 2x, 3.5x |
| Lens dimensions (mm) | 144×108 |
| Effective lens dimension (mm) | 139×103 |
| Lens material | optical glass |
| Working distance (mm) | 2x/160 3.5x/120 |
| Lens weight (g) | 2x/560 3.5x/730 |
| Lens method | Interchangeable lens “Recta System” lens system |
| AR (anti-reflection) coat lineup | Yes/2x, 3.5x |
| lighting | |
| light source | 27-inch compact fluorescent tube (FPL27) |
| input voltage | 100V・50/60Hz・A plug |
| power consumption | 24W |
| Dimming function | none |
| Main body | |
| Product weight (Kg) | OLIGHT3-F 2x approx. 3.2 / OLIGHT3-F 3.5x approx. 3.3 |
| Arm length (mm) | Approximately 1,000 (distance from clamp part to lens) |
| Head dimensions (mm) | 293×205 |
| Clampable width (mm) | 15-60 |
| Operating temperature limit | 5℃～40℃ |
| Dustproof/waterproof protection grade | IP20 (for indoor use only) |
